import java.awt.Color;
import java.awt.image.BufferedImage;
import java.awt.Image;
import java.awt.Graphics2D;
import java.io.File;
import java.io.FileWriter;
import java.io.IOException;
import java.io.PrintWriter;
import java.nio.file.Files;
import java.nio.file.Path;
import java.nio.file.Paths;
import javax.imageio.stream.ImageOutputStream;
import javax.imageio.stream.ImageInputStream;
import javax.imageio.metadata.IIOMetadata;
import javax.imageio.IIOImage;
import javax.imageio.ImageIO;
import javax.imageio.ImageWriteParam;
import javax.imageio.ImageWriter;
import javax.imageio.ImageReader;
import javax.imageio.ImageTypeSpecifier;
public class Pics {
private final String inDir = "images/"; // location of images
private final String outDir = "images/tmp/"; // location of created files
private String inFile;
private String resizedFile;
private String asciiFile;
private String greyScaleFile;
private String redScaleFile;
private String blueScaleFile;
private String greenScaleFile;
private String ext; // extension of file
private long bytes;
private int width;
private int height;
// Constructor obtains attributes of picture
public Pics(String name, String ext) {
this.ext = ext;
this.inFile = this.inDir + name + "." + ext;
this.resizedFile = this.outDir + name + "." + ext;
this.asciiFile = this.outDir + name + ".txt";
this.greyScaleFile = this.outDir + "Grey" + name + "." + ext;
this.redScaleFile = this.outDir + "Red" + name + "." + ext;
this.blueScaleFile = this.outDir + "Blue" + name + "." + ext;
this.greenScaleFile = this.outDir + "Green" + name + "." + ext;
this.setStats();
}
// An image contains metadata, namely size, width, and height
public void setStats() {
BufferedImage img;
try {
Path path = Paths.get(this.inFile);
this.bytes = Files.size(path);
img = ImageIO.read(new File(this.inFile));
this.width = img.getWidth();
this.height = img.getHeight();
} catch (IOException e) {
}
}
// Console print of data
public void printStats(String msg) {
System.out.println(msg + ": " + this.bytes + " " + this.width + "x" + this.height + " " + this.inFile);
}
// Convert scaled image into buffered image
public static BufferedImage convertToBufferedImage(Image img) {
// Create a buffered image with transparency
BufferedImage bi = new BufferedImage(
img.getWidth(null), img.getHeight(null),
BufferedImage.TYPE_INT_ARGB);
// magic?
Graphics2D graphics2D = bi.createGraphics();
graphics2D.drawImage(img, 0, 0, null);
graphics2D.dispose();
return bi;
}
// Scale or reduce to "scale" percentage provided
public void resize(int scale) {
BufferedImage img = null;
Image resizedImg = null;
int width = (int) (this.width * (scale/100.0) + 0.5);
int height = (int) (this.height * (scale/100.0) + 0.5);
try {
// read an image to BufferedImage for processing
img = ImageIO.read(new File(this.inFile)); // set buffer of image data
// create a new BufferedImage for drawing
resizedImg = img.getScaledInstance(width, height, Image.SCALE_SMOOTH);
} catch (IOException e) {
return;
}
try {
ImageIO.write(convertToBufferedImage(resizedImg), this.ext, new File(resizedFile));
} catch (IOException e) {
return;
}
this.inFile = this.resizedFile; // use scaled file vs original file in Class
this.setStats();
}
// convert every pixel to an ascii character (ratio does not seem correct)
public void convertToAscii() {
BufferedImage img = null;
PrintWriter asciiPrt = null;
FileWriter asciiWrt = null;
try {
File file = new File(this.asciiFile);
Files.deleteIfExists(file.toPath());
} catch (IOException e) {
System.out.println("Delete File error: " + e);
}
try {
asciiPrt = new PrintWriter(asciiWrt = new FileWriter(this.asciiFile, true));
} catch (IOException e) {
System.out.println("ASCII out file create error: " + e);
}
try {
img = ImageIO.read(new File(this.inFile));
} catch (IOException e) {
}
for (int i = 0; i < img.getHeight(); i+=3) {
for (int j = 0; j < img.getWidth(); j+=1) {
Color col = new Color(img.getRGB(j, i));
double pixVal = (((col.getRed() * 0.30) + (col.getBlue() * 0.59) + (col
.getGreen() * 0.11)));
try {
asciiPrt.print(asciiChar(pixVal));
asciiPrt.flush();
asciiWrt.flush();
} catch (Exception ex) {
}
}
try {
asciiPrt.println("");
asciiPrt.flush();
asciiWrt.flush();
} catch (Exception ex) {
}
}
}
// conversion table, there may be better out there ie https://www.billmongan.com/Ursinus-CS173-Fall2020/Labs/ASCIIArt
public String asciiChar(double g) {
String str = " ";
if (g >= 260) {
str = " ";
} else if (g >= 250) {
str = "'";
} else if (g >= 240) {
str = "-";
} else if (g >= 230) {
str = ",";
} else if (g >= 220) {
str = "\"";
} else if (g >= 210) {
str = ";";
} else if (g >= 200) {
str = "*";
} else if (g >= 190) {
str = ")";
} else if (g >= 180) {
str = "+";
} else if (g >= 170) {
str = "L";
} else if (g >= 160) {
str = "^";
} else if (g >= 150) {
str = "t";
} else if (g >= 140) {
str = "*";
} else if (g >= 130) {
str = "S";
} else if (g >= 120) {
str = "h";
} else if (g >= 110) {
str = "4";
} else if (g >= 100) {
str = "e";
} else if (g >= 90) {
str = "$";
} else if (g >= 80) {
str = "Q";
} else if (g >= 70) {
str = "N";
} else if (g >= 60) {
str= "B";
} else if (g >= 50) {
str = "#";
} else {
str = "@";
}
return str;
}
public void greyScale() {
BufferedImage img = null;
try {
File file = new File(this.greyScaleFile);
Files.deleteIfExists(file.toPath());
} catch (IOException e) {
System.out.println("Delete File error: " + e);
}
try {
img = ImageIO.read(new File(this.inFile));
} catch (IOException e) {
}
for (int i = 0; i < img.getHeight(); i++) {
for (int j = 0; j < img.getWidth(); j++) {
Color col = new Color(img.getRGB(j, i));
int grey = (int)(col.getRed()*0.3 + col.getGreen()*0.59 + col.getBlue()*0.11);
try {
Color rgb = new Color(grey, grey, grey);
img.setRGB(j, i, rgb.getRGB());
} catch (Exception ex) {
}
}
}
try {
ImageIO.write(img, "png", new File(this.greyScaleFile));
} catch (Exception ex) {
}
}
public void redScale() {
BufferedImage img = null;
try {
File file = new File(this.redScaleFile);
Files.deleteIfExists(file.toPath());
} catch (IOException e) {
System.out.println("Delete File error: " + e);
}
try {
img = ImageIO.read(new File(this.inFile));
} catch (IOException e) {
}
for (int i = 0; i < img.getHeight(); i++) {
for (int j = 0; j < img.getWidth(); j++) {
Color col = new Color(img.getRGB(j, i));
int red = (int)(col.getRed());
try {
Color rgb = new Color(red, 0, 0);
img.setRGB(j, i, rgb.getRGB());
} catch (Exception ex) {
}
}
}
try {
ImageIO.write(img, "png", new File(this.redScaleFile));
} catch (Exception ex) {
}
}
public void greenScale() {
BufferedImage img = null;
try {
File file = new File(this.greenScaleFile);
Files.deleteIfExists(file.toPath());
} catch (IOException e) {
System.out.println("Delete File error: " + e);
}
try {
img = ImageIO.read(new File(this.inFile));
} catch (IOException e) {
}
for (int i = 0; i < img.getHeight(); i++) {
for (int j = 0; j < img.getWidth(); j++) {
Color col = new Color(img.getRGB(j, i));
int green = (int)(col.getGreen());
try {
Color rgb = new Color(0, green, 0);
img.setRGB(j, i, rgb.getRGB());
} catch (Exception ex) {
}
}
}
try {
ImageIO.write(img, "png", new File(this.greenScaleFile));
} catch (Exception ex) {
}
}
public void blueScale() {
BufferedImage img = null;
try {
File file = new File(this.blueScaleFile);
Files.deleteIfExists(file.toPath());
} catch (IOException e) {
System.out.println("Delete File error: " + e);
}
try {
img = ImageIO.read(new File(this.inFile));
} catch (IOException e) {
}
for (int i = 0; i < img.getHeight(); i++) {
for (int j = 0; j < img.getWidth(); j++) {
Color col = new Color(img.getRGB(j, i));
int blue = (int)(col.getBlue());
try {
Color rgb = new Color(0, 0, blue);
img.setRGB(j, i, rgb.getRGB());
} catch (Exception ex) {
}
}
}
try {
ImageIO.write(img, "png", new File(this.blueScaleFile));
} catch (Exception ex) {
}
}
// tester/driver
public static void main(String[] args) throws IOException {
Pics ascii = new Pics("MonaLisa", "png");
ascii.printStats("Original");
ascii.resize(33);
ascii.printStats("Scaled");
ascii.convertToAscii();
Pics grey = new Pics("MonaLisa", "png");
grey.greyScale();
Pics red = new Pics("MonaLisa", "png");
red.redScale();
Pics green = new Pics("MonaLisa", "png");
green.greenScale();
Pics blue = new Pics("MonaLisa", "png");
blue.blueScale();
}
}
Pics.main(null);
ASCII: https://github.com/aidanywu/fastpages/blob/master/_notebooks/images/tmp/MonaLisa.txt
Grey:
Red:
Green:
Blue:
